High Breaking Capacity: With a 6 kA short circuit breaking capacity, it ensures effective protection in fault conditions.
Flexible Installation: Offers top or bottom line/load connection options, providing versatility in various installations.
Compatibility: Designed to work seamlessly with MAX4 18 mm pitch pin-type busbars, facilitating quick and secure connections.
Durability: Built to withstand the demands of residential, commercial, and light industrial applications, ensuring long-lasting performance.
Applications
Residential Electrical Systems: Protects circuits in homes and apartments from overloads and short circuits.
Commercial Installations: Suitable for small offices, retail spaces, and other commercial establishments requiring reliable circuit protection.
Light Industrial Applications: Ideal for protecting machinery and equipment in workshops and factories.
Switchboard Upgrades: Perfect for retrofitting existing panels to accommodate modern safety standards.
Feature |
Specification |
Rated Current (In) |
10 A |
Number of Poles |
3 (Three-phase) |
Tripping Curve |
C (Magnetic trip range: 5–10× In) |
Rated Voltage (Ue) |
415 V AC |
Short Circuit Capacity |
6 kA |
Mounting |
DIN Rail (18 mm pitch) |
Dimensions (W x H x D) |
54 mm x 81 mm x 78.5 mm |
Weight |
Approximately 0.356 kg |
Compliance |
AS/NZS 60898 |
