Three-Pole Protection: Safely disconnects all three live conductors in a three-phase system.
6kA Interrupting Capacity: Protects against short-circuit currents up to 6,000 Amps.
10A Current Rating: Designed for small-capacity loads, providing precise protection.
Thermal-Magnetic Trip Unit: Combines overload and short-circuit protection.
DIN Rail Mounting: Tool-free, fast installation on standard 35 mm DIN rails.
Resettable Design: Reusable after fault clearing—reducing maintenance cost.
Compliance with IEC Standards: Typically meets IEC 60898-1 or IEC 60947-2.
Tripping Curve Options: Available in B, C, or D curves for different load types.
Parameter |
Description |
Product Type |
Miniature Circuit Breaker (MCB) |
Series |
DL (Distribution Line) Series |
Poles |
3 Pole (3P) |
Rated Current (In) |
10 Amps |
Rated Voltage (Ue) |
400/415 V AC (Three-phase) |
Frequency |
50/60 Hz |
Breaking Capacity (Icu) |
6,000 Amps (6kA) |
Tripping Curve |
B, C, or D (application-dependent) |
Trip Mechanism |
Thermal-Magnetic |
Mounting Type |
DIN Rail (35 mm) |
