The Electra 10mm² Black SDI Cable is a high-performance, single-core, double-insulated electrical cable made to deliver dependable power in a variety of applications. This cable, which is rated at 450/750V and complies with Australian Standards AS/NZS 5000. 2, is appropriate for household, commercial, and industrial uses. It has a 3V90 PVC sheath and robust V90 PVC insulation and is made with stranded annealed copper for increased conductivity and flexibility.
Key Attributes:
Conductor: Stranded annealed copper (1x7/1. 35 mm) for outstanding conductivity and flexibility.
Insulation: 1. 0 mm thick V90 PVC insulation.
Sheath: a 0. 9 mm thick PVC sheath made of 3V90.
Rated voltage: 450/750 V.
Up to 90°C is the temperature rating.
Adherence to Standards: AS/NZS 5000. 2, AS/NZS 1125, and AS/NZS 3808.
Main Hue: Black.
White is the color of the sheath.
Radius of curvature: 35 mm.
DC: 1. 83 Ohm/km; AC: 2. 23 Ohm/km for conductor resistance.
| Specification |
Details |
| Conductor Size |
10 mm² |
| Stranding |
1x7/1.35 mm |
| Number of Cores |
1 Core |
| Overall Diameter |
8.2 mm |
| Insulation Thickness |
1.0 mm |
| Sheath Thickness |
0.9 mm |
| Bend Radius |
35 mm |
| Conductor Resistance |
DC: 1.83 Ohm/km; AC: 2.23 Ohm/km |
| Voltage Rating |
450/750V |
| Temperature Rating |
90°C |
| Standards Compliance |
AS/NZS 5000.2, AS/NZS 1125, AS/NZS 3808 |
| Core Colour |
Black |
| Sheath Colour |
White |
