Features:
Overcurrent Protection: Safeguards against overload and short circuit conditions.
Earth Leakage Protection: Provides protection against electrical shocks by detecting residual currents.
4.5kA Breaking Capacity: Ideal for environments with moderate fault levels.
DIN Rail Mounting: Easy installation and integration into standard distribution boards.
Type A Residual Current Detection: Protects against both AC and pulsating DC leakage currents.
Multiple Current Ratings: Available in different rated currents to suit varying load requirements.
Applications:
Residential: Protects household circuits, especially in kitchens, bathrooms, and wet areas where the risk of electric shock is higher.
Commercial: Suitable for office spaces, retail environments, and workshops where the likelihood of electrical faults may exist.
Industrial: Protects machinery, tools, and heavy equipment from electrical faults.
| Parameter |
Specification |
| Type |
RCBO (Residual Current Breaker with Overcurrent Protection) |
| Rated Current (In) |
16A, 20A, 25A, 32A, or 40A (depending on model) |
| Breaking Capacity (Icn) |
4.5kA |
| Tripping Curve |
C Curve (5–10× In), B Curve (3–5× In), or other (depending on model) |
| Rated Residual Operating Current (IΔn) |
30mA (personal protection), 100mA, or other (depending on model) |
| Voltage Rating (Ue) |
230V or 400V (single-phase or three-phase) |
| Frequency |
50/60Hz |
| Residual Current Type |
Type A (for AC and pulsating DC currents) |
| Poles |
1P, 2P, 3P, 4P (depending on model) |
| Mounting Type |
DIN Rail |
| Contact Position |
1 Normally Open (NO) |
