High Voltage Rating: Designed to handle the high voltages typical in modern PV systems, ensuring reliable protection.
Fast-Acting: Quick response to overcurrent conditions, minimizing potential damage to sensitive components.
High Interrupting Capacity: Capable of safely interrupting fault currents up to 50 kA, providing robust protection.
Durable Construction: Made with high-quality materials to withstand harsh environmental conditions.
Easy Installation: Compatible with standard DIN rail mounting, simplifying integration into existing systems.
Applications:
Inverters: Protecting the inverter from overcurrent situations.
Combiner Boxes: Safeguarding the junction points where multiple strings of solar panels converge.
PV String Circuits: Ensuring each string of panels is individually protected.
Battery Storage Systems: Preventing overcurrent conditions in energy storage setups.
Parameter |
Specification |
Current Rating |
25 Amps DC |
Voltage Rating |
1500V DC |
Fuse Type |
Fast-Acting |
Interrupting Rating |
Up to 50 kA |
Body Material |
Ceramic / Melamine |
Size |
10x85 mm |
Compliance |
IEC 60269-6, UL 248-19 |
Operating Temperature |
-30°C to +70°C |
Degree of Protection |
IP20 |
