Feature | Specification |
---|---|
Brand | Clipsal (by Schneider Electric) |
Series | Easy56 |
Model Number | EY56C532 |
Product Type | Switched Socket Outlet |
Pin Configuration | 5 Pin (3 Phase + Neutral + Earth) |
Current Rating | 32 Amps |
Voltage Rating | 500 Volts AC |
Frequency | 50 Hz |
IP Rating | IP66 (weather and dust resistant) |
Enclosure Material | UV-stabilised Polycarbonate |
Contact Material | Nickel-plated phosphor bronze |
Mounting Type | Surface Mounted |
Cable Entry Points | 2 x 20mm + 1 x 25mm rear threaded entries |
Switch Type | Rotary, Padlockable |
Compliance Standards | AS/NZS 3123 |
Colour Coding | Red (500V - Three-phase) |
Dimensions (H x W x D) | 204mm x 101mm x 108mm |
Operating Temperature | -25°C to +75°C |
Ingress Protection | Fully sealed against water jets and dust |
Lockable Switch | Yes (padlock provision) |
