Design & Build
Motor: Equipped with a 33W brushless DC motor, it operates quietly and efficiently.
Blades: Four ABS blades with a 15° pitch, ensuring optimal airflow.
Construction: The fan features a steel body with a matte black finish and an ABS canopy, contributing to its sleek appearance.
Mounting: Designed for flat ceiling installations, it has a slim profile with a drop of just 275mm, making it suitable for rooms with ceiling heights as low as 2.4 meters.
Lighting Features
Integrated LED Light: A 16W LED module provides illumination.
Color Temperature: Adjustable from 2700K (warm white) to 6000K (daylight), allowing customization to suit different moods and times of day.
Dimmable: The light is step-dimmable, with a maximum lumen output of 1885lm.
Lens Cover: Protected by a PMMA lens cover, ensuring durability and even light distribution.
Smart Connectivity
Wi-Fi Enabled: Compatible with the Smart Life and Tuya apps, enabling control via smartphone.
Voice Control: Works with voice assistants like Google Assistant and Amazon Alexa for hands-free operation.
Controls & Modes
Remote Control: Comes with an 8-speed remote control featuring a timer function.
Reversible Motor: Supports both summer (downdraft) and winter (updraft) modes, aiding in year-round comfort.
Additional Modes: Includes comfort sleep and breeze modes for enhanced user experience.
Specifications:
Motor Type: Brushless DC motor
Motor Wattage: 33W
Voltage: 220–240V AC, 50–60Hz
Air Movement: Up to 13,800 m³/hr
Number of Blades: 4
Blade Material: ABS plastic
Blade Pitch: 15°
Fan Size: 48" (1200mm–1220mm)
Speed Settings: 6 standard speeds + 2 unique modes (Comfort Sleep and Breeze)
Reversible Function: Yes, for both summer and winter modes via remote control
Installation Type: Close-to-ceiling (hugger style); flat surface level installation only
Overall Drop: 275mm from ceiling
