For high-performance electrical systems, the ELECTRA XLPE4160 is a 16mm², 4-core, black sheathed XLPE-insulated cable. It is appropriate for above-ground and subterranean power distribution in commercial, residential, and industrial environments because to its strong structure and excellent electrical properties. The cable is constructed to fulfill Australian and international requirements for durability and safety, and it has stranded copper conductors and XLPE insulation.
Important attributes:
With a voltage rating of 0.6/1 kV, it can be used in a variety of general power applications.
High Temperature Performance: Reliability throughout a range of working situations is ensured by its rating for continuous operation up to 90°C.
Sturdy Construction: Contains a durable Black 5V-90 PVC sheath for strong mechanical protection and insulation integrity, as well as XLPE X-90 insulation for exceptional thermal and electrical qualities.
Flexible Installation: As long as it is shielded from mechanical harm, it can be installed in a variety of ways, including direct burial, conduit, unenclosed, or underground ducts.
Clear Core Identification: For simple and secure phase identification in three-phase applications, this product includes standard Red, White, Blue, and Black cores.
Standards Compliant: High quality and safety are ensured in Australia and New Zealand by manufacturing in compliance with AS/NZS 1125, AS/NZS 3808, AS/NZS 5000.1, and AS/NZS 4026 standards.
Optimal Conductivity: For greatest efficiency and current carrying capacity, use plain annealed copper conductors.
Pre-packaged Length: Handy 100-meter drum for effective stock management or bigger projects.
| Specification |
Value |
| SKU |
XLPE4160 |
| Core Size |
16mm² |
| Number of Cores |
4 |
| Conductor Type |
Stranded Copper |
| Conductor Stranding |
Typically 7/1.7 mm |
| Insulation Material |
X-90 XLPE |
| Insulation Thickness (per core) |
1.5 mm |
| Sheath Material |
5V-90 PVC |
| Sheath Thickness |
1.5 mm |
| Voltage Rating |
0.6/1kV |
| Current Rating |
~76–100 Amps (depending on installation) |
| Max Conductor Temp |
90°C (continuous), 250°C (short circuit) |
| Bending Radius |
340 mm |
| Standards |
AS/NZS 5000.1, AS 4026, IEC 60332-1 |
