The NHP MOD6 3P+N 32A RCBO (M6RCBS3230CAN) offers a robust and reliable solution for integrated circuit protection.
Its dual functionality, combining MCB and RCD features, protects against both overcurrent and earth leakage faults in one compact device. With its 32 A rating, C-curve trip characteristic, and high short-circuit breaking capacity of 6 kA, it is ideally suited for applications with higher current demands.
The streamlined design—including a 3P+N configuration with a neutral pigtail and DIN rail mounting—ensures quick and secure installation in modern panelboards.
Additional features like the padlockable toggle and free tripping mechanism further enhance the safety and reliability of the device, making it a trusted choice for commercial, industrial, and mining electrical installations
FEATURES:
Overcurrent Protection: Acts as an MCB to interrupt excessive currents, safeguarding circuits from overloads and short circuits.
Earth Leakage Protection: Functions as an RCD with a 30 mA sensitivity (Type A), ensuring rapid disconnection in the event of an imbalance between live and neutral currents.
Rated Current: 32 A at 415 V AC, providing robust performance for higher load applications.
Trip Curve (C Curve): Optimized for general lighting and power circuits, and capable of accommodating moderate inrush currents (such as those from motor starting) without nuisance tripping.
Short-Circuit Breaking Capacity: Rated at 6 kA, ensuring that the device can safely interrupt high fault currents in compliance with AS/NZS 61009 standards.
3P+N Configuration: Offers a three-pole and neutral setup with an integrated neutral pigtail, reducing wiring complexity and installation time.
DIN Rail Mounting: Designed to be installed on a standard 35 mm top hat DIN rail, allowing for secure and space-efficient placement in electrical distribution panels.
| Specification |
Detailed Description |
| Product Model |
NHP MOD6 3P+N 32A PIGTAIL C CURVE 30mA Type A RCBO – Catalogue No. M6RCBS3230CAN |
| Product Type |
RCBO – An integrated device combining a miniature circuit breaker (MCB) and a residual current device (RCD) for overcurrent and earth leakage protection |
| Configuration |
3 Phase + Neutral (3P+N) with an integrated neutral pigtail to simplify wiring and installation |
| Rated Current |
32 A at 30°C – Maximum continuous current handling under standard operating conditions |
| Rated Voltage |
415 V AC – Suitable for typical three-phase supply systems |
| Residual (Leakage) Current |
30 mA (Type A) – Provides sensitive earth leakage protection that disconnects the circuit in the event of an imbalance |
| Trip Curve |
C Curve – Optimized for general lighting, power circuits, and moderate inrush currents (e.g., from motor starting), minimizing nuisance tripping |
| Frequency |
50/60 Hz – Compatible with standard international power frequency requirements |
| Short-Circuit Breaking Capacity |
6 kA – Rated to safely interrupt high fault currents, compliant with AS/NZS 61009 |
| Mounting Method |
DIN Rail – Designed to mount on a standard 35 mm top hat rail for secure and space-efficient installation in loadcentres and panelboards |
| Dimensions (mm) |
Height: 117.5 mm, Width: 54 mm, Depth: 71.6 mm – Compact dimensions matching the standard 3-pole width |
| Dimensions (cm) |
Height: 11.75 cm, Width: 5.4 cm, Depth: 7.16 cm – Converted for ease of reference |
| Weight |
Approximately 0.55 kg – Lightweight for easy handling and installation |
| Mechanical Life |
20,000 cycles – Ensures durability under repetitive mechanical operations |
| Electrical Life |
10,000 cycles – Reflects the number of tripping events the device is rated to reliably perform over its service life |
