Designed for DIN rail mounting, it offers a space-saving and easy-to-install option for modern electrical installations. Enhanced safety features such as a padlockable toggle and free tripping mechanism further secure its operation, making it a trusted choice for commercial, industrial, and critical applications.
Interrupts excessive current caused by overloads or short circuits, thereby protecting the circuit.
Provides sensitive leakage detection at 30 mA (Type A) to quickly disconnect the circuit if an imbalance is detected, reducing the risk of electrical shock.
A short-circuit breaking capacity of 6 kA ensures safe interruption of high fault currents in accordance with AS/NZS 61009 standards.
Designed for installation on standard 35 mm top hat DIN rails, ensuring a secure and space-saving setup in electrical panels.
FEATURES:
Space-Saving Dimensions: Compact form factor designed to occupy minimal space in loadcentres and panelboards.
Robust Build: Engineered with a high mechanical life (20,000 cycles) and electrical life (10,000 cycles) for long-term reliability.
Enhanced Safety Options: Features such as a padlockable operating toggle prevent unauthorized adjustments, and a free tripping mechanism
ensures reliable disconnection even when the toggle is locked.
1P+N Configuration: Features a single-pole design with a neutral connection (pigtail) that simplifies wiring and reduces installation time.
DIN Rail Mountable: Designed for installation on standard 35 mm top hat DIN rails, ensuring a secure and space-saving setup in electrical panels.
| Specification |
Detailed Description |
| Product Model |
NHP MOD6 1P+N C32A 30mA Type A RCBO – Catalogue No. M6RCBD3230CAN |
| Product Type |
RCBO – Integrated device combining a miniature circuit breaker (MCB) with a residual current device (RCD) for overcurrent and earth leakage protection |
| Configuration |
1P+N – Single-pole with neutral connection; includes an integrated neutral pigtail for simplified wiring and faster installation |
| Rated Current |
32 A at 30°C – Maximum continuous current under standard operating conditions |
| Rated Voltage |
415 V AC – Suitable for standard 1-phase supply systems |
| Residual (Leakage) Current |
30 mA (Type A) – Sensitive earth leakage detection that trips at 30 mA to protect against shock hazards |
| Trip Curve |
C Curve – Optimized for general lighting and power circuits; accommodates moderate inrush currents (e.g., motor starting) |
| Frequency |
50/60 Hz – Compatible with international power frequency standards |
| Short-Circuit Breaking Capacity |
6 kA – Rated to safely interrupt high fault currents in compliance with AS/NZS 61009 |
| Mounting Method |
DIN Rail – Designed for secure and space-efficient installation on a standard 35 mm top hat rail in loadcentres and panelboards |
| Mechanical Life |
20,000 cycles – Ensures durability through repeated mechanical operations |
| Electrical Life |
10,000 cycles – Reflects reliable performance across numerous tripping events |
