Its C-curve tripping characteristic is optimized for general lighting and power circuits and is designed to handle moderate inrush currents—such as those encountered when motors or similar loads start—while minimizing nuisance tripping.
The NHP MOD6 1P+N C20A 30mA Type A RCBO (M6RCBD2030CAN) delivers reliable, integrated protection for 1-phase circuits. Its dual-function design—combining both overcurrent and earth leakage protection—ensures safe operation under both normal and fault conditions.
With a 20 A rating, C-curve trip characteristic, and a 6 kA short-circuit breaking capacity, it is engineered for optimal performance in typical 1-phase applications.
Engineered with a robust mechanical life of 20,000 cycles and an electrical life of 10,000 cycles, ensuring long-term reliability in demanding environments.
FEATURES:
Detects imbalances between live and neutral currents and trips at 30 mA (Type A) to mitigate shock hazards.
Rated at 20 A and 415 V AC, it is designed for typical 1-phase applications with moderate load requirements.
Rated at 6 kA, ensuring safe interruption of high fault currents in compliance with AS/NZS 61009 standards.
Designed for installation on a standard 35 mm top hat DIN rail, which allows for secure and space-saving mounting in loadcentres and panelboards.
Its small footprint enables high-density installations without compromising performance.
| Specification |
Detailed Description |
| Product Model |
NHP MOD6 1P+N C20A 30mA Type A RCBO – Catalogue No. M6RCBD2030CAN |
| Product Type |
RCBO – Integrated device combining a miniature circuit breaker (MCB) with a residual current device (RCD) for dual overcurrent and earth leakage protection |
| Configuration |
1P+N – Single-pole with neutral connection; includes an integrated neutral pigtail for simplified wiring and faster installation |
| Rated Current |
20 A at 30°C – Maximum continuous current handling under standard operating conditions |
| Rated Voltage |
415 V AC – Suitable for typical 1-phase supply systems |
| Residual (Leakage) Current |
30 mA (Type A) – Sensitive earth leakage detection that trips at 30 mA to prevent electrical shock hazards |
| Trip Curve |
C Curve – Optimized for general lighting and power circuits; accommodates moderate inrush currents to reduce nuisance tripping |
| Frequency |
50/60 Hz – Compatible with standard international power frequency requirements |
| Short-Circuit Breaking Capacity |
6 kA – Rated to safely interrupt high fault currents in accordance with AS/NZS 61009 |
| Mounting Method |
DIN Rail – Designed for secure, space-efficient installation on a standard 35 mm top hat rail in loadcentres and panelboards |
| Mechanical Life |
20,000 cycles – Ensures long-term durability under repeated mechanical operations |
| Electrical Life |
10,000 cycles – Reflects the number of reliable tripping events over the device’s service life |
